Main Gate Railings

A gate is the first impression of your property. It must look elegant, provide security, and endure years without rust. Our main gate railings are crafted from high-grade aluminum-almost as strong as steel, yet only one third the weight. Lighter gates mean longer-lasting hinges and zero sag over time. Sizes and colors are fully customizable. Three opening styles are available: double-swing for wide entrances, single-swing for standard driveways, and sliding for tight spaces.

We use 6063-T5 or 6061-T6 aluminum. Yield strength ≥170 MPa. After heat treatment, hardness reaches HW12–HW14, close to soft steel. Aluminum's density is only 2.7 g/cm³ (steel: 7.8 g/cm³), making the gate light and easy on hinges. Heavy-duty stainless bearing hinges support 150 kg each, with grease fittings for long-term smooth operation. The space between vertical bars is ≤110 mm, meeting child safety standards. The main frame uses pipes ≥2.0 mm thick; shear strength is equivalent to 4 mm of standard steel plate.

Unlike steel, aluminum never rusts-even if scratched. Its natural oxide layer protects the surface in wet climates, acid rain, or coastal salt. Optional coatings include powder coat or outdoor-grade PVDF fluorocarbon paint, which preserves color for 15+ years.
